South Kraft


NAME

I.D. (in.)

W.P. (psi)

TUBE

COVER

APPLICATION

Commander® Air

1-1/4 to 2-1/2

400 to 650

SBR/NBR

Yellow; CR

High pressure air and water service; color-coded yellow.

Zephyr™

(2244, 0101)

1/2 to 2

500 to 1,000

NBR/SBR

Yellow; NBR/PVC

Heavy duty high pressure air service.

Valuflex® / General Service Red

(1145)

1/4 to 2

150 to 300

EPDM

Red; EPDM

Economical general service hose for various industrial, agricultural and construction applications where oil is not considered a significant factor.

Valuflex® / General Service Black

(1146)

1/4 to 2

150 to 300

EPDM

Black; EPDM

Economical general service hose for various industrial, agricultural and construction applications where oil is not considered a significant factor.

Maxecon®/GP

(3365)

1/4 to 1-1/2

250 to 300

NBR

Red; NBR/PVC

Air or water where moderate oil resistance is required. An excellent 300 psi industrial hose.

Cascade Paper Mill

(1782)

3/4 to 2-1/2

150

SBR

Gray; SBR

Hot water (200°F) wash-up in paper, pulp, and other processing mills.

Paper Mill Type 1788

(21284)

1/2 to 1-1/2

125 to 150

SBR

Gray; SBR

Hot water (200°F) wash-up in paper, pulp, and other processing mills.

Transporter® Water Discharge

(17825)

1-1/2 to 6

100

EPDM

Black; EPDM

Light industrial, irrigation, and construction use.

Transporter® Water
Suction & Discharge

(17834, 17830)

1-1/2 to 6

100 to 200

EPDM

Black; EPDM

For contractor and agricultural use. Rated full vacuum.

Burstproof™ Steam (Regular)

(2205, 110441)

1/2 to 2

250

EPDM

Black; EPDM

Quality steam hose for all types of general steam applications (406°F, 450°F superheated steam).

Burstproof™ Steam (Oil-Resistant)

(2206, 110442)

1/2 to 2-1/2

250

EPDM

Black; EPDM; RMA Class C (Medium Oil Resistance)

For areas where hose cover may come in contact with oil or grease (406°F, 450°F superheated steam).

Ultra-Chem®

(17709)

1 to 6

150 to 250

UHMWPE

Green (with Yellow Stripe); EPDM

Extremely flexible chemical transfer hose that handles 98% of all common industrial chemicals in pressure, gravity flow and suction service. Rated full vacuum.

Multi-Chem®

(17704)

1 to 4

150 to 200

XLPE

Green/Black (with Orange Stripe); EPDM

Extreme versatility, resists 95% of all industrial chemicals. Rated full vacuum.

Chemical H

(17703)

1 to 4

100 to 200

CSM

Yellow (with Red Stripe); CR

Designed primarily for the handling of inorganic acids, alcohols, and highly corrosive chemicals. Rated full vacuum.

Red/Black Tank Truck

(17813, 17811)

Red: 1-1/2 to 4

Black: 1 to 6

Red: 150

Black: 150 to 200

NBR

Red/Black; NBR/PVC

For transfer of petroleum-based products where strength, lightweight and flexibility are required. Service for most hydrocarbons, fats, greases, animal and vegetable oils, hydraulic fluid, and a wide range of chemicals. Rated full vacuum.

Paper Machine Suction Box

4-1/2 to 18

--

CR; Corrugated

Black; CR; Corrugated

Designed as a flexible connector on paper machines.

Material Suction

(17771)

1-1/2 to 4

100 to 150

3/16" NR White FDA

Blue; SBR

Handles a wide variety of materials: mild acids; dry materials such as sand, limestone and fertilizers; dry foods such as grain, flour and sugar and other non-oily edibles. Rated full vacuum.

Material Discharge

(17772)

2 to 4

100 to 150

3/16" NR White FDA

Blue (with Yellow Stripe); SBR

Handles a wide variety of materials: mild acids; dry materials such as sand, limestone and fertilizers; dry foods such as grain, flour and sugar and other non-oily edibles. Discharge service only.
